Dealing with Ownerless Groups in large Microsoft 365 environments

WIP

Scenario

Let say you administer a large Microsoft 365 environment (e.g. ~100k+ users and/or ~50K+ sites) and after some years you have a lot of ownerless groups and sites (around 5k probably), and a lot of inactive groups and sites (maybe 15k). You are getting more and more ownerless groups – dozens each week. You are thinking of stopping bleeding and cleaning this up…

Out-of-the-box we have Microsoft 365 groups expiration policy and Microsoft 365 ownerless groups policy. You might also have some 3-rd party tools implemented – e.g. ShareGate, SysKit Point.

If you do not care – you might just activate both OotB Microsoft policies – via GUI – they are simple to activate. But once you activated policies – they will trigger thousands of emails. Now imagine a person is getting dozens of emails asking him/her to be an owner or to renew the group that probably he/she has no idea about… What will happen next? People will probably ignore these alerts. Then? Groups and sites will be automatically deleted. And then? Right, there will be a huge noise and many angry users and high-priority tickets and you will have to restore sites/teams and finally you’ll have to deal with all that mess manually.

So, what is the right way to clean-up a large Microsoft 365 environment from ownerless and inactive teams, groups sites? Not a trivial question, hah?

Solution

Disclaimer: I’m sharing here my personal opinion with no obligations or warranty etc., so you’d dig into all the technologies used and based on your particular situation build your own plan. But my personal opinion is based on my 15+ years experience with SharePoint, including really large environments.

Note: It is always a good idea to discuss your plans with you org’s communication team and helpdesk/service-desk to adjust clean-up activities with other initiatives and let other people be prepared.

High-level steps for group-based Sites:

  • consider implementing Minimum 2 owners per group policy to stop bleeding. Currently Microsoft 365 does not have such functionality, so consider 3-rd party tool like SysKit Point or custom PowerShell script that sends notifications
    • apply this policy to groups where you already have 2+ owners – it’ll be safe
    • apply this policy to all other groups by chanks
  • consider custom PowerShell clean-up, e.g. you can simply delete groups with no owners and no members and/or inactive groups with no content and/or groups that are inactive for a long time (this must be aligned with business and legal)
  • implement Microsoft’s Ownerless groups policy in “Clean-Up” configuration; there are some tricks and gotchas worth a separate post, but in short
    • avoid scoping down this policy via people (security groups)
    • implement it for all groups all users with 6-7 weeks and custom e-mail template
  • implement Microsoft groups expiration policy in “Clean-Up” configuration… again, there are a few different strategies – see this article
  • change Microsoft Ownerless groups policy configuration to a “Permanent” mode configuration set
  • change Microsoft 365 groups expiration policy with a “Permanent” mode configuration

Note: There will always be ownerless groups in large environment. We have to live with it.

All above was mostly about group-based sites (as we have OotB Microsoft policies for groups), but we probably have the same problem (or even worth) with standalone sites (that would be a separate topic).

You cannot use Power BI to visualize this list issue

If you are working with SharePoint Online list and select Integrate – Power BI – Visualize the list, but it gives you error message “You cannot use Power BI to visualize this list”, “Looks like the feature for visualizing lists is turned off. Please contact your admin to enable this feature”:

You cannot use Power BI to visualize this list

The issue appears to be not in SharePoint, but in Power BI. Note it says “You cannot use Power BI to visualize this list” and “Looks like the feature for visualizing lists is turned off. Please contact your admin to enable this feature.”

Also the url of this page is Power BI Url:
“https://app.powerbi.com/sharepointlist?spListId=%7Bd3b56”, so you’d need contact Power Platform Administrators, not SharePoint administrators.

Power BI administrator would go to Microsoft Fabric Admin portal

and ensure “Integration with SharePoint and Microsoft Lists” is Enabled for the entire organization or for specific security groups. In the last case – ensure user who is getting “You cannot use Power BI to visualize this list” is added to at least one of the groups but not added to “Except specific groups”.

If the user is allowed under “Integration with SharePoint and Microsoft Lists” so “Users in the organization can launch Power BI from SharePoint lists and Microsoft Lists. Then they can build Power BI reports on the data in those lists and publish them back to the lists.” then, normally, user would see:

and something like:

Calling Microsoft Graph API from Python

Below is how I authenticate and call Microsoft Graph API to work with SharePoint from Python application.

Plain

no MSAL or Azure libraries used:

import requests
import json
from secrets import clientSc

clientId = "7e60c372-ec15-4069-a4df-0ab47912da46"
# clientSc = "<imported>"
tenantId = "7ddc7314-9f01-45d5-b012-71665bb1c544"

apiUri = "https://login.microsoftonline.com/" + tenantId + "/oauth2/v2.0/token"

body = {
    "client_id"     : clientId,
    "client_secret" : clientSc,
    "scope"         : "https://graph.microsoft.com/.default",
    "grant_type"    : "client_credentials"
}

response = requests.post(apiUri, data=body)
token = json.loads(response.content)["access_token"]

graph_url = 'https://graph.microsoft.com/v1.0/sites/root'
site = requests.get(
    graph_url,
    headers={'Authorization': 'Bearer {0}'.format(token)}
)

print(site.content)
print(json.loads(site.content)["webUrl"])

secrets is a Python file where I assign client secret to variable clientSc (so my secret is not shared on github). This is ok for demo purposes but generally, you should not hard-code secrets but keep secrets somewhere safe (Vault).

MSAL

Using MSAL library to get bearer token:
https://github.com/VladilenK/m365-with-Python/tree/main/Graph-API-MSAL

References

Providing ACS permissions for app to access SharePoint

Microsoft retires ACS

Let me quote Microsoft just to start (Dec 18, 2023):

  • “SharePoint App-Only is the older, but still very relevant, model of setting up app-principals.”
  • “… we will be retiring the use of Azure ACS (Access Control Services) for SharePoint Online auth needs and believe Microsoft 365 customers will be better served by modern auth…”
  • “Azure ACS will stop working for new tenants as of November 1st, 2024 and it will stop working for existing tenants and will be fully retired as of April 2nd, 2026…
    There will not be an option to extend using Azure ACS with SharePoint Online beyond April 2nd, 2026″
  • “… we recommend switching those applications to use Microsoft Entra ID for authorization and authentication needs…”

So, for new development it is strictly recommended to use Azure Registered Apps to access Microsoft 365 resources programmatically.

You still need ACS in some cases

But, as always, it all is not so simple, as

  • there are still plenty of 3-rd party applications written and used widely that require ACS-based permissions. Moreover, there are still some 1-st party applications (Microsoft apps and services) that require ACS-based permissions
  • though Microsoft Graph API is good and provide a lot of functionality and is developing rapidly, it cannot cover all SharePoint dev’s needs, so using SharePoint REST API could be unavoidable… and that is where some complications are coming
  • permissions to specific SharePoint sites (not to all tenant sites, but to one or several SharePoint sites in tenant) for apps is done via Sites.Selected, but this works to entire site collection only. E.g. via Sites.Selected you cannot provide granular permissions (e.g. to specific list) for an app, which might be crucial in some cases, so you’d still have to use ACS-based permissions

Hopefully, Microsoft will resolve all the issues above before April 2026… But for now we have to live with both – Azure Registered applications and API permissions configured in Entra ID and with SharePoint app-only service principals and ACS-based permissions.

Azure Apps and Entra Id vs SharePoint app-only spn and ACS

Comparison between Azure Apps and Entra Id API permissions vs SharePoint app-only spn and ACS-based permissions

ACS-based SharePoint app/permissionsApps registered in Azure with Sites.Selected API permissions
support authentication with client secret only, secret is valid for 1 year exactlysupport authentication with client secret and/or certificate, custom expiration time
support granular access to SharePoint site content – e.g. to entire site collection or web (subsite) or a specific listsupport only access to entire site collection (but Microsoft is working on granular access)
support only classic SharePoint REST API and CSOMsupport both – classic SharePoint REST API and CSOM and Microsoft Graph API
app id (client id) is created via appregnew.aspx at a specific SharePoint site by site collection administratorapp id (client id) is created in Azure portal, API Sites.Selected permissions are configured via Azure portal and require tenant admin consent
permissions for the app to a site are provided at the site by site collection administrator via appinv.aspx pagepermissions for the App to to a specific SharePoint site are provided by SharePoint admin with PowerShell script or Graph API calls
logging audit log

SharePoint app-only service principal and ACS-based permissions

Since SharePoint app-only service principals and ACS-based permissions were introduced for SharePoint 2013 as part of Add-Ins feature – there are plenty of articles from Microsoft and MVPs and SharePoint gurus on this. But I would like to highlight one thing:

  • AppRegNew page creates service principal and allows authentication
  • AppInv page provides permissions and allows authorization to SharePoint

Check SharePoint AppRegNew.aspx and AppInv.aspx for details

Recommended transition tactics

WIP…

References

Using SharePoint REST API from Python code

Using Microsoft Graph API is a preferred and recommended way to connect to SharePoint Online and other Microsoft 365 resources programmatically from Python code. But if by some reason you are required to use classic SharePoint REST API, here is how it is done.

Prerequisites:

  • Azure Registered Application
    you must register your application in Azure and configure it properly
    • Authentication blade must be configured for authenticate as current user
    • Certificates and/or secrets must be configured for daemon app (unattended access)
  • API permissions
    your Azure app registration must have API permissions configured based on resources you need access to and authentication method chosen
    here is how to configure API permissions for your app
  • Office365-REST-Python-Client library installed

Using client Id and client secret to access SharePoint REST API from Python

Errors

Possible errors and diagnostic messages

HTTPError: 401 Client Error: Unauthorized for url…
The provided client secret keys for app … are expired. Visit the Azure portal to create new keys for your app or consider using certificate credentials for added security

Code samples at GitHub

WIP…

References

Search in SharePoint using Microsoft Graph API with application credentials

Microsoft Graph API allows you to work with all the Microsoft 365 content – including search through Exchange e-mail messages, Yammer (Viva Engage) and Teams chat messages and surely OneDrive and SharePoint content (please refer to the original doc). Let me focus on searching in SharePoint Online and OD here but you can use the same technique to search through other Microsoft 365 services. I will use PowerShell but same ideas should work for other platforms/languages – Python, C#, node.js etc.

Assuming we have a registered Azure app configured correctly, including Secrets/Certificates blade and API permissions provided – we should be ready to authenticate and call Graph API unattended – on behalf of application itself.

Let us authenticate as a service/daemon app with client id and client secret:

# Authenticate to M365 as an unattended application

# specify your app id. app secret, tenant id:
$clientID = ""
$clientSc = ""
$TenantId = ""

# Construct URI and body needed for authentication
$uri = "https://login.microsoftonline.com/$tenantId/oauth2/v2.0/token"
$body = @{
    client_id     = $clientID
    client_secret = $clientSc
    scope         = "https://graph.microsoft.com/.default"
    grant_type    = "client_credentials"
}

# Get OAuth 2.0 Token
$tokenRequest = Invoke-WebRequest -Method Post -Uri $uri -ContentType "application/x-www-form-urlencoded" -Body $body -UseBasicParsing
$token = ($tokenRequest.Content | ConvertFrom-Json).access_token
$headers = @{Authorization = "Bearer $token" }

Below is how I search Microsoft 365 content programmatically from PowerShell using MS Graph API being authenticates as user.

# Search
$entityTypes = "['driveItem','listItem','list','drive','site']"
$entityTypes = "['driveItem','listItem']"

$query = "LastModifiedTimeForRetention<2021-01-01"
$apiUrl = "https://graph.microsoft.com/beta/search/query"
$query = "test*"
$body = @"
{
  "requests": [
    {
      "entityTypes": $entityTypes,
      "query": {
        "queryString": "$query"
      },
      "from" : 0,
      "size" : 5,
      "fields": ["WebUrl","lastModifiedBy","name" ],
      "region": "NAM"
    }
  ]
}
"@

$res = Invoke-RestMethod -Headers $Headers -Uri $apiUrl -Body $Body -Method Post -ContentType 'application/json'
$res.value[0].searchTerms
$res.value[0].hitsContainers[0].hits
$res.value[0].hitsContainers[0].hits.Count
$res.value[0].hitsContainers[0].moreResultsAvailable

Notice we use “region” – it is required to search with Graph API under application credentials. Otherwise you will get an error message “SearchRequest Invalid (Region is required when request with application permission.)”:

Parameter “fields” allows you to request only fields you need to be returned. As returning object will be smaller your request will perform faster.

There might be a big number of objects found in m365 upon your request. Graph will not always return to you all the results. AFAIK currently the limit is 500, so if there are more than 500 objects found – only first 500 will be returned. You can specify how many objects you need to be returned per call with “size” parameter.

You can check value of $res.value[0].hitsContainers[0].moreResultsAvailable property and if it’s True – that means there are more results. The value above and parameters “from” and “size” would allow you to organize a loop so you can call search API many times to return all results.

Other articles index:
Search m365 SharePoint and Teams content programmatically via MS Graph API

Using Microsoft Graph Search API: user context

Assuming we have a registered Azure app configured correctly, including Authentication and API permissions provided – we should be ready to authenticate and call Graph API on behalf of a user.

Microsoft Graph API allows you to work with all the Microsoft 365 content – including search through Exchange e-mail messages, Yammer (Viva Engage) and Teams chat messages and surely OneDrive and SharePoint content (please refer to the original doc).

Let me focus on searching in SharePoint Online and OD here but you can use the same technique to search through other Microsoft 365 services. I will use PowerShell but same ideas should work for other platforms/languages – Python, C#, node.js etc.

Let us authenticate first. We’d need a MSAL.PS module for that.

# Ensure we have MSAL.PS module installed
Get-Module MSAL.PS -ListAvailable | ft name, Version, Path
# Install-Module MSAL.PS -Force -Scope CurrentUser -AcceptLicense
Import-Module MSAL.PS

# Authenticate to Microsoft Interactively
$clientid = 'd82858e0-ed99-424f-a00f-cef64125e49c' # your client id
$TenantId = '7ddc7314-9f01-45d5-b012-71665bb1c544' # your tenant id
$token = Get-MsalToken -TenantId $TenantId -ClientId $clientid -Interactive
$headers = @{Authorization = "Bearer $($token.AccessToken)" }

Below is how I search Microsoft 365 content programmatically from PowerShell using MS Graph API being authenticates as user.

# Search
# MS Graph Search API url (beta or v1.0):
$apiUrl = "https://graph.microsoft.com/beta/search/query"

# specify where to search - entity types
$entityTypes = "['driveItem','listItem','list','drive','site']"
$entityTypes = "['driveItem','listItem']"

# query
$query = "test*"

# build a simple request body
$body = @"
{
  "requests": [
    {
      "entityTypes": $entityTypes,
      "query": {
        "queryString": "$query"
      }
    }
  ]
}
"@

# call Graph API:
$res = Invoke-RestMethod -Headers $Headers -Uri $apiUrl -Body $Body -Method Post -ContentType 'application/json'

# explore returned object
$res.value[0].searchTerms
$res.value[0].hitsContainers[0].hits
$res.value[0].hitsContainers[0].hits.Count
$res.value[0].hitsContainers[0].moreResultsAvailable

References

Authorization to Microsoft Graph: Azure Registered Apps API permissions

Being authenticated to Microsoft 365 tenant means Microsoft 365 knows who is trying to get access. To actually be able read/write or manage resource, your app must be Authorized to this resource.

For details – pls refer to MS authorization and Microsoft Graph API permissions. But again, in short in our case that means we need to have an API permission configured for our azure registered app. There are two kinds of API permissions – delegated and application.

Delegated permissions are intended to allow currently authenticated user to have access to the resource. Effective user permissions in this app would be an intersection of user own permissions and app permissions. So if an app have “Sites.FullControl.All” SharePoint delegated API permissions – that does not mean that user will have full control over all sites.

Application permissions are what it says – once permissions are configured – application will have access to the resources according to API permissions.

Generally, application permissions allow an app to have access to all resources of the same kind in tenant, e.g. to get one specific groups owners an app must have “GroupMember.Read.All” permission that allows an app to read all tenant groups and their members. There are some exceptions – e.g. for Teams Microsoft developed RSC that allows scoped app access. For SharePoint there is a similar option – “Sites.Selected” API permissions.

API permissions must have an Admin consent (see below).

References
